“Utilizing Stainless Steel Protector Sleeves”
Cable railing installation tips for wooden cable railings: A popular and cost effective choice for constructing cable railings, and cable fences. Wood framing is typically a warmer and more natural feel for those rustic or landscape style railing applications that do not call for more contemporary stainless steel railing posts. Despite the cost benefits, wood posts do require different considerations for a successful cable railing installation.
Wood selection and wood types will play a large role in the longevity of a cable railing system. Common exterior wood types include western red cedar, redwood, douglas fir, and Ipe Brazilian hardwood. Timbers should contain minimal knots, and feature tight grain whenever availability permits. Clear timbers are typically stronger than construction grade timbers.
One simple and inexpensive way to add durability to wooden cable railing posts is by utilizing stainless steel sleeves inside the cable perforations. Stainless steel protector sleeves will assure that when turning a corner, bending, or traveling through jigs and jogs, the cable does not “bite”into wood framing members. “Biting” can result in loss of cable tension or damage to wood railing posts.
In addition to the added protection, the cables will tension faster and react against a hard stainless steel sleeve vs. a softer wooden post. Stainless steel protector sleeves also help by reducing moisture intrusion, and provide a more finished look than bare wood perforations. Even hardwood posts like Ipe and Mangaris require stainless sleeves when bending occurs.
San Diego Cable Railings offers stainless steel sleeves for a la carte purchase at the online store. Our preferred installers utilize stainless steel protector sleeves on all wood framed cable railing applications. If you have questions about stainless steel protector sleeves please visit www.sandiegocablerailings.com or call us at 844-277-7327.
Cable Railing Installation Tips: utilizing stainless steel cable and protector sleeves:
